  • Light Duty - Wide Wheel - Series Swivel Top Plate - Capacity to 220 lbs

  • Design: heavy gauge cold rolled steel, formed for strength.
  • Finish: bright zinc plating to resist rust and corrosion.
  • Swivel Construction: double ball bearing with hardened raceways.
  • Axle: 3/8" diameter bolt with lock nut.
  • Brake options are available, contact Sales
  • Top Plate Sizes: to order, add Plate Mounting Code to end of model number
  • PLT 1: Top Plate Size 2-7/16” x 2-7/16” Bolt Hole Spacing 1-3/4” x 1-3/4” Mounting Bolt Size 1/4”.
  • PLT 2: Top Plate Size 1-3/4” x 3” Bolt Hole Spacing 1” x 2-1/4” Mounting Bolt Size 1/4”.
  • PLT 4: Top Plate Size 2-3/8” x 3-5/8” Bolt Hole Spacing 1-3/4” x 3” Mounting Bolt Size 5/16”.

    •

1 - 25 of 42 | Results Per Page | View | Unit of Measure
1 2
Request Information Compare Items Search by Specification

Item #

IntegrationID

Weight

Series

Wheel Diameter

Tread Width

Wheel Type

Wheel Bearing

Capacity

Load Height

Swivel Radius

Caster Type

Caster Type Psearch

N/A
78795 		N/A 1.75 lbs N/A W25 N/A 3.00 in N/A 1.25 in N/A Cushion Rubber N/A Delrin N/A 110 lbs N/A 4.13 in N/A 3.00 in N/A Swivel N/A Swivel
N/A
78796 		N/A 1.75 lbs N/A W25 N/A 3.00 in N/A 1.25 in N/A Cushion Rubber N/A Ball N/A 110 lbs N/A 4.13 in N/A 3.00 in N/A Swivel N/A Swivel
N/A
78797 		N/A 1.75 lbs N/A W25 N/A 3.00 in N/A 1.25 in N/A Hard Rubber N/A Delrin N/A 160 lbs N/A 4.13 in N/A 3.00 in N/A Swivel N/A Swivel
N/A
78798 		N/A 1.75 lbs N/A W25 N/A 3.00 in N/A 1.25 in N/A Hard Rubber N/A Ball N/A 160 lbs N/A 4.13 in N/A 3.00 in N/A Swivel N/A Swivel
N/A
78799 		N/A 1.75 lbs N/A W25 N/A 3.00 in N/A 1.25 in N/A Polyolefin N/A Plain N/A 180 lbs N/A 4.13 in N/A 3.00 in N/A Swivel N/A Swivel
N/A
78800 		N/A 1.75 lbs N/A W25 N/A 3.00 in N/A 1.50 in N/A Phenolic N/A Plain N/A 220 lbs N/A 4.13 in N/A 3.00 in N/A Swivel N/A Swivel
N/A
78801 		N/A 2.38 lbs N/A W25 N/A 4.00 in N/A 1.25 in N/A Cushion Rubber N/A Delrin N/A 120 lbs N/A 5.13 in N/A 3.50 in N/A Swivel N/A Swivel
N/A
78802 		N/A 2.38 lbs N/A W25 N/A 4.00 in N/A 1.25 in N/A Cushion Rubber with Side Plates N/A Ball N/A 120 lbs N/A 5.13 in N/A 3.50 in N/A Swivel N/A Swivel
N/A
78803 		N/A 2.50 lbs N/A W25 N/A 4.00 in N/A 1.25 in N/A Welded Disk / Black Rubber N/A Ball N/A 150 lbs N/A 5.13 in N/A 3.50 in N/A Swivel N/A Swivel
N/A
78804 		N/A 2.50 lbs N/A W25 N/A 4.00 in N/A 1.25 in N/A Welded Disk / Grey Rubber N/A Ball N/A 150 lbs N/A 5.13 in N/A 3.50 in N/A Swivel N/A Swivel
N/A
78805 		N/A 2.38 lbs N/A W25 N/A 4.00 in N/A 1.25 in N/A Hard Rubber N/A Delrin N/A 180 lbs N/A 5.13 in N/A 3.50 in N/A Swivel N/A Swivel
N/A
78806 		N/A 2.38 lbs N/A W25 N/A 4.00 in N/A 1.25 in N/A Hard Rubber with Side Plates N/A Ball N/A 180 lbs N/A 5.13 in N/A 3.50 in N/A Swivel N/A Swivel
N/A
78807 		N/A 2.50 lbs N/A W25 N/A 4.00 in N/A 1.25 in N/A Advantage Thermoplastic Rubber / Round N/A Delrin N/A 180 lbs N/A 5.13 in N/A 3.50 in N/A Swivel N/A Swivel
N/A
78808 		N/A 2.50 lbs N/A W25 N/A 4.00 in N/A 1.25 in N/A Advantage Thermoplastic Rubber / Round N/A Ball N/A 180 lbs N/A 5.13 in N/A 3.50 in N/A Swivel N/A Swivel
N/A
78809 		N/A 2.50 lbs N/A W25 N/A 4.00 in N/A 1.25 in N/A Welded Disk / Polyurethane N/A Ball N/A 200 lbs N/A 5.13 in N/A 3.50 in N/A Swivel N/A Swivel
N/A
78810 		N/A 2.50 lbs N/A W25 N/A 4.00 in N/A 1.25 in N/A Polyloc / Grey N/A Ball N/A 200 lbs N/A 5.13 in N/A 3.50 in N/A Swivel N/A Swivel
N/A
78811 		N/A 2.50 lbs N/A W25 N/A 4.00 in N/A 1.25 in N/A Polyloc / Grey N/A Delrin N/A 200 lbs N/A 5.13 in N/A 3.50 in N/A Swivel N/A Swivel
N/A
78812 		N/A 2.50 lbs N/A W25 N/A 4.00 in N/A 1.25 in N/A Polyloc / Blue N/A Ball N/A 200 lbs N/A 5.13 in N/A 3.50 in N/A Swivel N/A Swivel
N/A
78813 		N/A 2.50 lbs N/A W25 N/A 4.00 in N/A 1.25 in N/A Polyolefin N/A Plain N/A 200 lbs N/A 5.13 in N/A 3.50 in N/A Swivel N/A Swivel
N/A
78814 		N/A 2.50 lbs N/A W25 N/A 4.00 in N/A 1.25 in N/A Advantage Thermoplastic Rubber / Flat N/A Delrin N/A 220 lbs N/A 5.13 in N/A 3.50 in N/A Swivel N/A Swivel
N/A
78815 		N/A 2.50 lbs N/A W25 N/A 4.00 in N/A 1.25 in N/A Advantage Thermoplastic Rubber / Flat N/A Ball N/A 220 lbs N/A 5.13 in N/A 3.50 in N/A Swivel N/A Swivel
N/A
78816 		N/A 2.50 lbs N/A W25 N/A 4.00 in N/A 1.50 in N/A Phenolic N/A Plain N/A 220 lbs N/A 5.13 in N/A 3.50 in N/A Swivel N/A Swivel
N/A
78817 		N/A 2.75 lbs N/A W25 N/A 5.00 in N/A 1.25 in N/A Cushion Rubber N/A Delrin N/A 150 lbs N/A 6.25 in N/A 4.00 in N/A Swivel N/A Swivel
N/A
78818 		N/A 2.75 lbs N/A W25 N/A 5.00 in N/A 1.25 in N/A Conductive Cushion Rubber N/A Sintered N/A 150 lbs N/A 6.25 in N/A 4.00 in N/A Swivel N/A Swivel
N/A
78819 		N/A 2.75 lbs N/A W25 N/A 5.00 in N/A 1.25 in N/A Cushion Rubber N/A Ball N/A 150 lbs N/A 6.25 in N/A 4.00 in N/A Swivel N/A Swivel
